OPD 25-300-Š-10
Code: Y29-25-300S00Product detailed description
Steel grouting packer terminated with M10x1 screw, suitable for connection of Shaft locking M10x1 plastic or nipple M32. It is designed for high pressure grouting of concrete and masonry. The packer has a large inside diameter and thus allows a higher delivery of grouting material.Additional parameters
| Category: | Ending of packer by screw |
|---|---|
| Weight: | 0.203 kg |
| Connection method: | M10x1 nut or mixer body |
| Total length in mm: | 300 |
| Designed for bore diameter in mm: | 26 |
| Recommended grouting materials: | polyurethanes, epoxies, acrylates, microcements |
| Maximum pressure: | 250 bar |
| Minimum pressure for opening the valve in the nipple in bar: | 0 bar |
| Designed for: | concrete, brick, stone |
| Benefits: | easy assembly and disassembly |
